Device |
Output
Current(A) |
Output
Voltage (V) |
Initial
Tolerance (%) |
Package
Availability |
Dropout
Voltage (V) |
Operating
Temperature
(°C) |
|
AMS1082
|
10
|
Adj,1.5,
2.5, 2.85, 3.0,
3.3, 3.5, 5.0
|
±1
|
3L
TO-220, 3L TO-263
|
1.3
|
0
to +125
|
|
AMS1083
|
8
|
Adj,1.5,
2.5, 2.85, 3.0,
3.3, 3.5, 5.0
|
±1
|
3L
TO-220, 3L TO-263
|
1.3
|
0
to +125
|
|
AMS1084
|
5
|
Adj,1.5,
2.5, 2.85, 3.0,
3.3, 3.5, 5.0
|
±1
|
3L
TO-220, 3L TO-263,
TO-252
|
1.3
|
0
to +125
|
|
AMS1085
|
3
|
Adj,1.5,
2.5, 2.85, 3.0,
3.3, 3.5, 5.0
|
±1
|
3L
TO-220, 3L TO-263,
TO-252
|
1.3
|
0
to +125
|
|
AMS1086
|
1.5
|
Adj,1.5,1.8,
2.5, 2.85, 3.0,
3.3, 3.5, 5.0
|
±1
|
SOT-223,3L
TO-220, 3L TO-263,
TO-252
|
1.3
|
0
to +125
|
|
AMS1501
|
1.5
|
Adj,1.5,
2.5, 2.85, 3.0,
3.3, 3.5, 5.0
|
±1
|
5L
TO-220, 5L TO-263,
5L TO-252
|
1.15/0.45
|
0
to +125
|
|
AMS1503
|
3
|
Adj,1.5,
2.5, 2.85, 3.0,
3.3, 3.5, 5.0
|
±1
|
5L
TO-220, 5L TO-263,
5L TO-252
|
1.15/0.45
|
0
to +125
|
|
AMS1505
|
5
|
Adj,1.5,
2.5, 2.85, 3.0,
3.3, 3.5, 5.0
|
±1
|
5L
TO-220, 5L TO-263,
5L TO-252
|
1.15/0.45
|
0
to +125
|
|
AMS1508
|
8
|
Adj,1.5,
2.5, 2.85, 3.0,
3.3, 3.5, 5.0
|
±1
|
5L
TO-220, 7L TO-220,
5L TO-263
|
1.15/0.45
|
0
to +125
|
|
AMS1510
|
10
|
Adj,1.5,
2.5, 2.85, 3.0,
3.3, 3.5, 5.0
|
±1
|
5L
TO-220, 7L TO-220,
5L TO-263
|
1.15/0.45
|
0
to +125
|
|
AMS1505V
|
5
|
Adj,1.5,
2.5, 2.85, 3.0,
3.3, 3.5, 5.0
|
±1
|
5L
TO-220, 5L TO-263
|
1.15/0.20
|
0
to +125
|
|
AMS1585
|
4.6
|
Adj,1.5,
2.5, 2.85, 3.0,
3.3, 3.5, 5.0
|
±1
|
3L
TO-220, 3L TO-263
|
1.2
|
0
to +125
|
|
AMS1587
|
3
|
Adj,1.5,
2.5, 2.85, 3.0,
3.3, 3.5, 5.0
|
±1
|
3L
TO-220, 3L TO-263
|
1.2
|
0
to +125
|
| AMS2115 |
Customer
Dependent |
Adj,1.5,
1.8, 2.5, 3.3,
5.0 |
±1
|
8L
SOIC |
Customer
Dependent |
0
to +125
|
|
AMS2501/2502
|
1
|
Adj,1.5,
1.8, 2.5, 2.85,
3.0, 3.3, 3.5,
5.0 |
±1
|
8L
SOIC
|
0.5
|
0
to +125
|
|
AMS317
|
1
|
Adj,1.8,
2.5, 2.85, 3.3,
5.0, *
|
±2,
±3
|
SOT-223,
TO-252, 3L TO-220,
3L TO-263
|
1.3
|
0
to +125
|
|
AMS2910
|
1
|
Adj,1.5,1.8,
2.5, 2.85, 3.3,
5.0, *
|
±1
|
SOT-223,
TO-252, 3L TO-220,
3L TO-263
|
1.3
|
0
to +125
|
|
AMS2906
|
0.6
|
Adj,1.5,1.8,
2.5, 2.85, 3.3,
5.0, *
|
±1
|
SOT-223,
TO-252, SOT-89
|
1.3
|
0
to +125
|
|
AMS1117
|
1
|
Adj,1.5,
1.8, 2.5, 2.85,
3.3, 5.0, *
|
±1
|
SOT-223,
TO-252, SO-8
|
1.3
|
0
to +125
|
|
AMS2911
|
1
|
Adj,1.5,1.8,
2.5, 2.85, 3.3,
5.0, *
|
±1
|
SOT-223,
TO-252, 3L TO-220,
3L TO-263
|
1.3
|
0
to +125
|
|
AMS2908
|
0.8
|
Adj,1.5,
1.8,2.5, 2.85,
3.3, 5.0, *
|
±1
|
SOT-223,
TO-252
|
1.3
|
0
to +125
|
|
AMS2905
|
0.5
|
Adj,1.5,1.8,
2.5, 2.85, 3.3,
5.0, *
|
±1
|
SOT-223,
TO-252, SOT-89
|
1.3
|
0
to +125
|
|
|
0.5
|
Adj,1.5,1.8,
2.5, 2.85, 3.3,
5.0, *
|
±1
|
SOT-223,
TO-252, SOT-89
|
1.3
|
0
to +125
|
|
AMS78LXX
|
0.1
|
5.0,
6.2, 8.0
|
±4
|
TO-92,
SO-8, SOT-89
|
0.6
|
0
to +125
|
|
AMS3106
|
0.5
|
Adj.,
0.6V to 6V in 0.1V step * |
±1,
±2
|
SOT-23-5, SO-8
|
0.2
|
-40
to +125
|
|
AMS3107
|
0.5
|
Adj.,
2.0, 2.5, 3.3,
3.5, 4.0, 5.0,
* |
±1,
±3
|
TO-92,
SOT-89, SOT-223,
SO-8, TO-252
|
0.15
|
-25
to +125
|
|
AMS500
|
0.5
|
Adj.,
2.0, 2.5, 3.3,
3.5, 4.0, 5.0,
* |
±4
|
TO-92,
SOT-89, SOT-23-5
|
0.25
|
-25
to +125
|
|
AMS5105
|
0.5
|
Adj.,
1.5, 1.8, 2.5, 2.8, 3.3,
* |
±1.5,
±3
|
SOT-89, SOT-223,
SOT-23-5, SO-8
|
0.4
|
-25
to +125
|
|
AMS3102
|
0.3
|
Adj.,
2.0, 2.5, 3.3,
3.5, 4.0, 5.0,
* |
±1,
±3
|
TO-92,
SOT-89, SOT-23-3,
SOT-23-5, SO-8
|
0.3
|
-25
to +125
|
|
AMS2954
|
0.25
|
Adj,2.5,
3.0, 3.3, 5.0,
* |
±
0.5, ±1
|
TO-220,
TO-263, TO-252,
SOT-223, SO-8,
8L PDIP
|
0.38
|
-40
to +125
|
|
AMS3101
|
0.15
|
Adj, 0.6V to 6V in 0.1V step* |
±
1, ±2
|
SOT-23-5
|
0.2
|
-40
to +125
|
|
AMS2930
|
0.15
|
Adjustable,
5.0, *
|
±
3.8, ±5
|
TO-92,
SO-8, TO-220,
TO-263
|
0.3
|
-40
to +125
|
|
AMS2931
|
0.1
|
Adjustable,
5.0, *
|
±
3.8, ±5
|
TO-92,
SO-8, TO-220,
TO-263
|
0.3
|
-40
to +125
|
|
LP2950
|
0.1
|
2.5,
3.0, 3.3, 5.0,
* |
±
0.5, ±1
|
TO-92
|
0.38
|
-40
to +125
|
|
LP2951
|
0.1
|
2.5,
3.0, 3.3, 5.0,
* |
±0.5,
±1
|
SO-8,
8L PDIP
|
0.38
|
-40
to +125
|
|
AMS2950
|
0.15
|
2.5,
3.0, 3.3, 5.0,
* |
±0.5,
±1
|
TO-92
|
0.38
|
-40
to +125
|
|
AMS2951
|
0.15
|
2.5,
3.0, 3.3, 5.0,
* |
±0.5,
±1
|
SO-8,
8L PDIP
|
0.38
|
-40
to +125
|
|
AMS112
|
0.15
|
3.3,
5.0, *
|
±3
|
5L
SOT-23
|
0.16
|
-30
to +80
|
|
AMS116
|
0.1
|
5.0,
* |
±3
|
TO-92,
SOT-89
|
0.17
|
-40
to +125
|
|
AMS2942
|
0.10
|
1.23
to 42, *
|
±1.2,
±2
|
8L
SOIC
|
0.38
|
-40
to +125
|
|
AMS431L
|
0.15
|
1.24
to 20
|
±0.5,
±1,
±2
|
TO-92,
SOT-89, SOT-23-3,
SOT-23-5
|
|
-40
to +125
|
|
AMS431
|
0.15
|
2.5
to 36
|
±0.25,
±0.5,
±1
|
TO-92,
SO-8, SOT-89,
SOT-23
|
|
-40
to +125
|
|
AMS3431
|
0.15
|
2.5
to 36
|
±0.25,
±0.5,
±1
|
TO-92,
3L SOT-23
|
|
-40
to +85
|
|
AMS421
|
0.01
|
0.5
to 15
|
±0.5,
±1,
±2
|
SOT-23-5
|
|
-40
to +125
|
|
|
AMS1082
series of adjustable
and fixed voltage
regulators are designed
to provide 10A output
current and to operate
down to 1V input-to-output
differential. The
dropout voltage of
the device is guaranteed
maximum 1.5V at maximum
output current, decreasing
at lower load currents.
On-chip trimming adjusts
the reference voltage
to 1%. Current limit
is also trimmed, minimizing
the stress under overload
conditions on both
the regulator and
power source circuitry.
The AMS1082 devices
are pin compatible
with older three-terminal
regulators and are
offered in 3 lead
TO-220 package and
3 lead TO-263 (Plastic
DD).
